The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Graphic LCD Module |2.4" 132x64 STN-| White Display on Blue | ST7567 | SPI | Arduino HTM-C0G13264C01A-25W-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | |||
| Graphic LCD Module | 132x64 STN Display+ | Yellow-Green Backlight | ST7567 | SPI | Arduino HTM-C0G13264C01A-11Y-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | |||
| Graphic LCD Module | STN+ | 2.4" 132x64 Display Blue on Gray | ST7567 | SPI | Arduino HTM-C0G13264C01A-11W-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | |||
| Graphic LCD Module | DFSTN-| 2.4" 132x64 Display White on Black | ST7567 | SPI | Arduino HTM-C0G13264C01A-41W-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | |||
| Graphic LCD Module | FSTN+ |132x64 LCD Display | ST7567 | SPI | Arduino HTM-C0G13264C01A-31W-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | |||
| Graphic LCD Module | STN+Yellow-Green |132x64 Display | ST7567 |SPI | Arduino HTM-C0G13264C01A-01Y-SPI | Graphic LCD Module | 132x64 |
|
66.0x56.2x5.5 | 53.2x31.5 | 48.81x26.21 | 0.41x0.37 | 6H | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3 V | ST7567 | |||
| Graphic LCD Module | STN- | 8.9" 160X160 White on Blue | UC1698 | MCU | Arduino | 3.3V HTM160160E-25W-N3P | Graphic LCD Module | 160x160 |
|
83.8*76.5*8.5 | 60.0*60.0 | 54.4*54.4 | 0.34x0.34 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | UC1698 | |||
| Graphic LCD Module | STN+ | 8.9" 160X160 Yellow-Green Backlight | UC1698 | MCU | Arduino | 3.3V HTM160160E-11Y-N3P | Graphic LCD Module | 160x160 |
|
83.8*76.5*8.5 | 60.0*60.0 | 54.4*54.4 | 0.34x0.34 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3 V | UC1698 | |||
| Graphic LCD Module | STN+ | 8.9" 160X160 Gray Background with Blue Text | UC1698 | MCU | Arduino | 3.3V HTM160160E-11W-N3P | Graphic LCD Module | 160x160 |
|
83.8*76.5*8.5 | 60.0*60.0 | 54.4*54.4 | 0.34x0.34 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | UC1698 | |||
| Graphic LCD Module | DFSTN- | 8.9" 160X160 White on Black | UC1698 | MCU | Arduino | 3.3V HTM160160E-41W-N3P | Graphic LCD Module | 160x160 |
|
83.8*76.5*8.5 | 60.0*60.0 | 54.4*54.4 | 0.34x0.34 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | 0.34x0.34 |
